ماژول صفحه نمایش ماتریسی 16 * 16 تک رنگ

[magmagmary]

ماژول صفحه نمایش ماتریسی 16 * 16 تک رنگ



نمونه کد :

/*
  * Show messages on an 8x8 led matrix,
  * scrolling from right to left.
  *
  * Uses FrequencyTimer2 library to
  * constantly run an interrupt routine
  * at a specified frequency. This
  * refreshes the display without the
  * main loop having to do anything.
  *
  */


#include <FrequencyTimer2.h>


#define SPACE { \
     {0, 0, 0, 0, 0, 0, 0, 0},  \
     {0, 0, 0, 0, 0, 0, 0, 0}, \
     {0, 0, 0, 0, 0, 0, 0, 0}, \
     {0, 0, 0, 0, 0, 0, 0, 0}, \
     {0, 0, 0, 0, 0, 0, 0, 0}, \
     {0, 0, 0, 0, 0, 0, 0, 0}, \
     {0, 0, 0, 0, 0, 0, 0, 0}, \
     {0, 0, 0, 0, 0, 0, 0, 0} \
}


#define H { \
     {0, 1, 0, 0, 0, 0, 1, 0}, \
     {0, 1, 0, 0, 0, 0, 1, 0}, \
     {0, 1, 0, 0, 0, 0, 1, 0}, \
     {0, 1, 1, 1, 1, 1, 1, 0}, \
     {0, 1, 0, 0, 0, 0, 1, 0}, \
     {0, 1, 0, 0, 0, 0, 1, 0}, \
     {0, 1, 0, 0, 0, 0, 1, 0}, \
     {0, 1, 0, 0, 0, 0, 1, 0}  \
}


#define E  { \
     {0, 1, 1, 1, 1, 1, 1, 0}, \
     {0, 1, 0, 0, 0, 0, 0, 0}, \
     {0, 1, 0, 0, 0, 0, 0, 0}, \
     {0, 1, 1, 1, 1, 1, 1, 0}, \
     {0, 1, 0, 0, 0, 0, 0, 0}, \
     {0, 1, 0, 0, 0, 0, 0, 0}, \
     {0, 1, 0, 0, 0, 0, 0, 0}, \
     {0, 1, 1, 1, 1, 1, 1, 0}  \
}


#define L { \
     {0, 1, 0, 0, 0, 0, 0, 0}, \
     {0, 1, 0, 0, 0, 0, 0, 0}, \
     {0, 1, 0, 0, 0, 0, 0, 0}, \
     {0, 1, 0, 0, 0, 0, 0, 0}, \
     {0, 1, 0, 0, 0, 0, 0, 0}, \
     {0, 1, 0, 0, 0, 0, 0, 0}, \
     {0, 1, 0, 0, 0, 0, 0, 0}, \
     {0, 1, 1, 1, 1, 1, 1, 0}  \
}


#define O { \
     {0, 0, 0, 1, 1, 0, 0, 0}, \
     {0, 0, 1, 0, 0, 1, 0, 0}, \
     {0, 1, 0, 0, 0, 0, 1, 0}, \
     {0, 1, 0, 0, 0, 0, 1, 0}, \
     {0, 1, 0, 0, 0, 0, 1, 0}, \
     {0, 1, 0, 0, 0, 0, 1, 0}, \
     {0, 0, 1, 0, 0, 1, 0, 0}, \
     {0, 0, 0, 1, 1, 0, 0, 0}  \
}


byte col = 0;
byte leds[8][8];


// pin[xx] on led matrix connected to nn on Arduino (-1 is dummy to make array start at pos 1)
int pins[17]= {-1, 5, 4, 3, 2, 14, 15, 16, 17, 13, 12, 11, 10, 9, 8, 7, 6};


// col[xx] of leds = pin yy on led matrix
int cols[8] = {pins[13], pins[3], pins[4], pins[10], pins[06], pins[11], pins[15], pins[16]};


// row[xx] of leds = pin yy on led matrix
int rows[8] = {pins[9], pins[14], pins[8], pins[12], pins[1], pins[7], pins[2], pins[5]};


const int numPatterns = 6;
byte patterns[numPatterns][8][8] = {
   H,E,L,L,O,SPACE
};


int pattern = 0;


void setup() {
   // sets the pins as output
   for (int i = 1; i <= 16; i++) {
     pinMode(pins[i], OUTPUT);
   }


  // set up cols and rows
   for (int i = 1; i <= 8; i++) {
     digitalWrite(cols[i - 1], LOW);
   }


  for (int i = 1; i <= 8; i++) {
     digitalWrite(rows[i - 1], LOW);
   }


  clearLeds();


  // Turn off toggling of pin 11
   FrequencyTimer2::disable();
   // Set refresh rate (interrupt timeout period)
   FrequencyTimer2::setPeriod(2000);
   // Set interrupt routine to be called
   FrequencyTimer2::setOnOverflow(display);


  setPattern(pattern);
}


void loop() {
     pattern = ++pattern % numPatterns;
     slidePattern(pattern, 60);
}


void clearLeds() {
   // Clear display array
   for (int i = 0; i < 8; i++) {
     for (int j = 0; j < 8; j++) {
       leds[i][j] = 0;
     }
   }
}


void setPattern(int pattern) {
   for (int i = 0; i < 8; i++) {
     for (int j = 0; j < 8; j++) {
       leds[i][j] = patterns[pattern][i][j];
     }
   }
}


void slidePattern(int pattern, int del) {
   for (int l = 0; l < 8; l++) {
     for (int i = 0; i < 7; i++) {
       for (int j = 0; j < 8; j++) {
         leds[j][i] = leds[j][i+1];
       }
     }
     for (int j = 0; j < 8; j++) {
       leds[j][7] = patterns[pattern][j][0 + l];
     }
     delay(del);
   }
}


// Interrupt routine
void display() {
   digitalWrite(cols[col], LOW);  // Turn whole previous column off
   col++;
   if (col == 8) {
     col = 0;
   }
   for (int row = 0; row < 8; row++) {
     if (leds[col][7 - row] == 1) {
       digitalWrite(rows[row], LOW);  // Turn on this led
     }
     else {
       digitalWrite(rows[row], HIGH); // Turn off this led
     }
   }
   digitalWrite(cols[col], HIGH); // Turn whole column on at once (for equal lighting times)
}


کتابخانه در فایل ضمیمه
